Features
-"Blinky-mode" provides a fair racing environment between racers. (Shows that all timing advance switched to zero)
-Stunning size and weight
-Easy-to-use programming
-Firmware update available
-Programmed by Android system, via Ensotech - UARTLINK-II (optional) (Product Code: UARTLK-II)
-Programmed by Android system via (optional) wireless Bluetooth adaptor "EnsoBlueth" (December 2018), a
fully functional connection to change settings, update firmware and show telemetry.
-Professional set of customized parameters for the difficult race track
-ESC protection in case of one or two Hall sensor wire break
-Automatic recognition of Hall sensor’s position even when wire connections are swapped
-Settings configurations export and import. (You can save and load configuration or share out)
-Aluminum body for better heating dissipation
Specification: Swave-E2
Swave-E2
Dimensions (mm):
21.8(L)*12.7(W)*7.8(H)
Weight:
4g
Supply Voltage:
2s LiPo / 2s LiOn
Const./Brust Current (A):
14/20A (under 90 degree Celsius)
Sensor input:
1 (5 pins)
Programming input:
1
Receiver input:
1
Support motor type (Sensored):
Slotless 15mm Brushless DC up to 5500kv
Support motor type (Sensorless):
Slotless 15mm/16mm Brushless DC
BEC Output:
1.0A (max.)
Android App Version
1.4.3 or later
Specification: Swave-W
Swave-W
Dimensions (mm):
25.1(L)*13.2(W)*7.86(H)
Weight:
4g
Supply Voltage:
2s LiPo / 2s LiOn
Const./Brust Current (A):
20/30A (under 90 degree Celsius)
Sensor input:
1 (5 pins)
Programming input:
1
Receiver input:
1
Support motor type (Sensored):
Slotless 15mm Brushless DC up to 8000kv
Support motor type (Sensorless):
Slotless 15mm/16mm Brushless DC
BEC Output:
1.5A (max.)
Android App Version
1.4.3 or later
