ENSTROM 480B - SECTION VI. WEIGHT AND BALANCE

5-9-12 ENSTROM 480B OPERATOR'S MANUAL
FAA Approved: May 21/19 Rev. 24
Report No. 28-AC-023 May 2/19
SECTION VI. WEIGHT AND BALANCE
5-9-14. General
1. A new weight and balance should be recalculated
per the instructions in Chapter 6 of the Basic Flight Manual
using the information listed below.
Table 5-9-1. Weight and Balance Information
(Standard Kit)
Equipment
Weight
(lbs)
Arm
(in)
Moment
(in-lbs)
Searchlight Mount with
Electrical Harness
5.4 170.1 918.5
Junction Box**
6.3 222.0 1398.6
Searchlight/Gimbal
Assembly
21.5 171.3 3683.0
Total* 33.2 180.7 6000.1
Table 5-9-2. Weight and Balance Information
(Elevated Kit)
Equipment
Weight
(lbs)
Arm
(in)
Moment
(in-lbs)
Searchlight Mount with
Electrical Harness
7.8 168.8 1316.6
Junction Box**
6.3 222.0 1398.6
Searchlight/Gimbal
Assembly
21.5 171.3 3683.0
Total* 35.6 179.7 6398.2
* Total does not include control box and cable (1.5 lbs)
or non-removable portion of electrical harness.
** Standard location; location may vary depending on
other optional equipment installations.
