MN-39165 • Rev 2 • 09/17 • 230V EC Series Fluid Warmer
4
Installation
Preparation Before Operating the Appliance
1. Clean the interior and exterior with a damp cloth and mild soap solution.
2. Wipe with an appropriate disinfectant.
3. Wipe dry with a clean cloth or air dry.
To prevent serious personal injury, death, or
property damage:
Do not steam clean, hose down or flood the
interior or exterior with water or liquid solution
of any kind. Do not use water jet toclean. Failure
to observe this precaution will void the warranty.
To prevent serious personal injury, death,
or property damage:
Do not use this warming appliance in
the presence of flammable anesthetic
mixtures (with air or with oxygen or
nitrous oxide).
Not category AP or APG equipment
Fluid warming chamber:
The warming appliance can be programmed to warm
either irrigation uids (IRR) or injection uids (INJ), with
separate temperature ranges provided depending on the
choice selected.
• IRR temperature range: 37°C to 66°C (98°F to 150°F),
• INJ temperature range: 37°C to 40°C (98°F to 104°F).
A fan located inside the chamber mixes the air to prevent
temperature strati cation and to ensure an accurate
chamber temperature for each mode.
• Within +0/-1.12°C (+0/-2ºF) for set points of
37°C to 40°C (98°F to 104°F).
• Within +0/-1.67°C (+0/-3ºF) for set points of
43°C to 66°C (110°F to 150°F)
An alarm will sound if temperatures exceed 6°C (10°F) over
the set-point temperature, and an overtemp indicator will
blink indicating an over-temperature condition.
EC230L Information:
General Information
EC340L Information:
This warming appliance is designed to safely warm and
store either irrigation uids or injection uids.
The single-chambered warming appliance is constructed
with stainless steel exterior casing and door with handle
and hinges designed to withstand heavy usage. A door
with window allows observation of inventory. The cabinet
is warmed using a low-heat-density electrothermal cable
array. The electrothermal cable is positioned in the oor
and two sides of the warming cabinet, providing even
heating of the interior chamber.
The interior chamber temperature is regulated by
an electronic control consisting of a 4 digit LED
display, on/off button, increase and decrease buttons,
integrated lock-out control feature, and a series of
prompt sequence indicators.
The electronic control can be set to operate in fahrenheit
or celsius. A er a power failure, the appliance will
remember its programming and begin to operate as
before. The on/off indicator will blink to indicate a
failure occurred; pressing the on/off button once will
eliminate this blinking. A thermal shut-off system,
separate from the electronic control, is included as an
additional safety feature.
The electronic control will display temperature in
whole degrees.
EC770L Information:
Fluid warming chamber:
The warming appliance can be programmed to warm
either irrigation uids (IRR) or injection uids (INJ), with
separate temperature ranges provided depending on the
choice selected.
• IRR temperature range: 37°C to 66°C (98°F to 150°F),
• INJ temperature range: 37°C to 40°C (98°F to 104°F).
A fan located inside the chamber mixes the air to prevent
temperature strati cation and to ensure an accurate
chamber temperature for each mode.
• Within +0/-1.12°C (+0/-2ºF) for set points of
37°C to 40°C (98°F to 104°F).
• Within +0/-1.67°C (+0/-3ºF) for set points of
43°C to 66°C (110°F to 150°F)
An alarm will sound if temperatures exceed 6°C (10°F) over
the set-point temperature, and an overtemp indicator will
blink indicating an over-temperature condition.
The appliance is equipped with three (3) white, epoxy-
coated wire baskets to accommodate uids packaged in
bags or bottles, mounted on basket rail supports. Each
basket has a capacity of 18 1-liter bottles (54 total) or 24
1-liter bags (72 total). The appliance is furnished with a
full perimeter rubber bumper assembly and one set of
5" (127mm) heavy-duty casters – two (2) rigid and two (2)
swivel with locking brake.
The appliance is equipped with two (2) white, epoxy-
coated wire baskets to accommodate uids packaged in
bags or bottles, mounted on basket rail supports. Each
basket has a capacity of 9 1-liter bottles (18 total) or 15
1-liter bags (30 total). The appliance is furnished with a
full perimeter rubber bumper assembly and one set of
5" (127mm) heavy-duty casters – two (2) rigid and two (2)
swivel with locking brake.
The appliance is equipped with one (1) white, epoxy-
coated wire basket to accommodate uids packaged in
bags or bottles, mounted on basket rail supports. The
basket has a capacity of 11 1-liter bottles or 16 1-liter bags.
The appliance is furnished with four (4) 1-1/4" (31mm)
non-skid rubber feet.
To Next Page
