Entrya D22S - Advanced Electrical Installations; Wiring for Multiple Door Stations; Door Station Addressing; Lock Wiring with Internal Power

10
Ω
BUS(DS) BUS(IM) BUS BUS
BUS BUSBUS BUS
BUS
Mastercode 1 - 4# ##11
SD41
BUS
CV-AP- CV+AP+
CCTV
GNDCOM
C
1 2 3
1 2 3
All texts and images in this manual are protected by copyright and intellectual property
of ENTRYA TECHNOLOGIES BVBA.
V.101120210942
Electrical installation of more door stations
Address 1 Address 3Address 2 Address 4
Set address of the door station Default: 1
Electrical installation of a lock
Schematic for Lock 1 with internal power supply
Exit-button for manual unlocking
Max. 12V DC, 300mA
The lock is not active in standby (NO)
The lock is active in standby (NC)
LK-JP
