Envirco MAC 10 - Page 10

MAC 10 LE-AC SERVICE MANUAL
9 EGAP
Figure 5 – RSR Sheet Metal Filter Replacement
Fan Filter Unit
Filter Clip and
Screw (typ 6)
Filter
Filter
Clip
Gel
Track
Perforated
Screen
¼ -20
Cap
Screw
Knife-edge
Seal
2-Piece Welded
Plenum Housing
Diffuser Screen
Screws (typ 6)
10-32 PHP
Screws
