MAC 10 LE-AC SERVICE MANUAL
31 EGAP
Figure 7 – RSRE Motor Replacement
Figure 8 –Motor Blower Components
Electrical connectors
located in inner
prefilter wall
Plenum
Gel Seal Filter
Motor/Blower
A
ss
y
Venturi
Ring
Screen
Motor
Blower
Wheel
Loosen Bolt to
remove Motor
Baffle Assembly
