9
INSTALLATION GUIDE
Lay the Top Filler Panel onto the top Ganging
Brackets, in between the Side Filler Panels.
Note: For a single back-to-back table, only a Single
Top Filler Panel is used (shown in Figure 4.9).
For a run of tables, there are only 2 End
Top Filler Panels at each end of the run, and
multiple Mid Top Filler Panels in between.
**Reference Page 1 Parts and Fasteners images
for proper Top Filler Panel identication.**
If your accessories have already been attached
to the table then re attach doors from step 1.
Otherwise, proceed to section 6.
FIGURE 4.10
FIGURE 4.11
4) ASSEMBLY: GANGING
