If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of
this product, contact Customer Service via
customercare@hingear.com.
Before starting assembly, verify all parts are included and undamaged. Improper installation may cause damage or
weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or
inappropriate use.
This product contains small items that could be a choking hazard if swallowed. NOT FOR CHILDREN UNDER 3 YEARS.
ADULT SUPERVISION IS REQUIRED.
NOTE: Not all hardware included will be used.
DO NOT EXCEED WEIGHT CAPACITY.
WARNING!
01
PACKAGE CONTENTS
(17.6lbs)x2
(8kg)x2
B (x1)
Swivel Arm
C (x1)
Clamp
D (x1)
Pole
G (x3)
Bolt
F (x1)
Base Plate
L(x1)
4mm Allen Key
H(x1)
Support Plate
M(x1)
6mm Allen Key
J(x2)
Plastic Cover
K(x2)
Bolt
I(x4)
Wire clip
E(x1)
Wire Clip
A (x2)
VESA Plate
M-E(x8)
D6 Washer
M-A (x8)
M4x12
M-B (x8)
M4x16
M-C (x8)
M6x12
M-D (x8)
M6x16
M-F (x8)
Spacer
