STEP 1: (Continued)
OPTION B: Grommet Base Installation
before installing the desk mount.
Loosen the screw, separate the C-clamp (C) into two parts.
Install the Grommet Base Plate (F) to the Pole using 1pc Bolt (G). Position pole (D) on the
mounting surface and secure using the support plate (H) and the bolt separated from clamp (C).
Secure the pole to the desktop by tightening the plastic knob or by using 6mm Allen key (M).
10-80mm
D
F
H
G
M
OR
C
DESK
DESK
ø0.39"~3.1"
