The height of your seat is adjusted by a quick-locking system. Pull on the
quick-release lever. Insert your seat post at least up to the minimum insertion line
indicated on the seat post. Tighten the adjusting nut with the quick-release lever
and then push the quick-release lever to the closed position.
The seat angle is adjusted using the nuts that secure the seat to the seat
rail. Ensure that the nuts are tight and that the seat does not move forward or
backward when you sit on it.
Adjusting the seat cushion
The adjustment method is as follows:
Loosen the manual seat post unlocking, remove the seat post from the
saddle; Adjust the screw, bring the seat post back into the frame tube as the old
position and tighten the seat position clamp.
Using the LCD screen
LCD-07
LCD display version for City one, 4 Speed, Comfort models.
