Please note:
the output will cut off once there is over load or short circuit. While short circuit for 1st time, the
controller will resume to work automaticaly after 30 seconds. Check the load,press the switch to start
when it happened again.
1. After over discharged, the controller will resume to work when the battery is charged to 13.1V. (for 12V
system only, for 24v, use 2X)
After over discharged, the controller will resume to work while you press the power switch, note the battery
voltage needs to be over 12.5V.
To correct problem
1. Check wires
2. Reduce amps if needed
3. Reset controller
 Disconnect battery +
 Reconnect battery +
RATINGS (12V or 12/24V auto work)
EPHC-5 80Watts or 5 Amps for Solar and Load
EPHC-10 170Watts or 10 Amps for Solar and Load
NOTES: For use with solar panels only
TECHNICAL INFORMATION
 Regulations point 14.4 Volts
 Low voltage Disconnect 11.1V Volts
 Low voltage Reconnect 13.1 Volts
Note: all is for 12V system only, use 2x for 24 Volt system
 Microcontroller digital accuracy
 Type of Charging Series PWM & stat of charge(SOC)
4 Stages: equalization, PWM, Boost and Float,
temperature compensated charging
 Electronic protections Short circuit and over current-solar and load
Reverse polarity-solar, load, battery
Reverse current at night
Limits high voltage to protect loads
Lighting protection
 Tropicalization Conformal coated printed circuit board
 Terminals For wire sizes to 4mm²
 Weights 250g
 Dimension 140*90.5mm
 Self-consumption 6mA maximum
 Temperature -35℃to 55℃
 Enclosure IP22
 Warranty 3 years
 Compliance CE

