Please read all instructions before
installing your equipment.
Technical data
● Voltage: 10-24 VDC
● 36W
● Consumption: 1 A max
● Flash patterns: 12
● Mounting: Permanent
● Total # of Leds: 6 for each lamp
Cable configuration
● Red Cable: VCC
● Black Cable: GND
● White Cable: to define type of flash (Pulse to Vcc)
● Green Cable: To synchronize with another light
Recommendations:
The equipment is designed for external use of the vehicle.
The equipment must have adequate ventilation.
