Fig. 6
⚫ The charging must take place in an area that is well ventilated and capable of removing the hydrogen gas
that is generated by the charging process. A minimum of five air exchanges per hour is recommended
⚫ The charging connector components are in good condition and free from dirt or debris.
⚫ The charger connector is fully inserted into the vehicle receptacle.
⚫ The charger connector/cord set is protected from damage and is located in an area to prevent injury that may
result from personnel running over or tripping over the cord set.
⚫ The charger is automatically turned off during the connect/disconnect cycle and therefore no electrical arc is
generated at the DC plug/receptacle contacts.
In our chargers, there is a jiggle switch inside charger receptacle. The switch is part of the interlock
system that prevents the vehicle from being driven when the charger plug is inserted in the vehicle charging
receptacle. (Fig 7)
Fig. 7
