6
1.
Attach the Small Stabilizer (2) to the Frame (1)
w
ith two M10 x 90mm Bolts (18), two M10
W
ashers (23), and two M10 Nylon
Locknuts (24).
1
Before beginning assembly, make sure
that you understand all the information
o
n page 5.
24
24
18
1
2
23
23
2. Orient the Large Stabilizer (3) so that the high
side of the mounting bracket is on the side
shown. Attach the Large Stabilizer to the Frame
(1) with two M10 x 15mm Screws (21) and two
M10 Washers (23).
21
1
3
High side of
mounting bracket
2
3. Orient the Deck (4) as shown, and press it onto
the Frame (1).
Next, attach the Seat Frame (5) to the Frame
(1) with two M10 x 65mm Screws (20) and two
M10 Washers (23).
Then, tighten the Backrest Knob (11) into the
Seat Frame (5).
4. See the inset drawing. Locate the bracket weld-
ed to the back of the Backrest Frame (6).
Attach the Backrest Bracket (7) to the bracket
on the Backrest Frame (6) with two M10 x
25mm Bolts (17), two M10 W
ashers (23), and
two M10 Nylon Locknuts (24).
3
1
5
20
11
4
17
7
6
23
23
23
24
23
4
Bracket
6
To Next Page
