Power Handling 150 Watts unclipped speech and music
Frequency Range 44 Hz - 25 kHz
Impedance 4 Ohm nominal
Sensitivity 92dB /2.83V@1m
Amplifier Compatibility 12.5 - 150 Watts
Positioning Not less than 10 cm (4”) from rear wall
Tweeter Epos 25mm soft dome with high-temperature voice coil, ferrofluid cooling and
neodymium magnet system. Magnetically shielded
Bass/and Bass/Midrange Drivers 2x Epos mid-bass 156mm dia., with cast chassis, 25mm high-temperature voice coil and
polypropylene cone
Crossover Frequencies 3.6kHz and 800Hz
Crossover Bass, mid bass and tweeter networks all use 2nd order filters. Only metal oxide resistors
and polypropylene film capacitors are used for optimum sound quality. The tweeter
section has an air-cored inductor. Both the woofer and mid-woofer sections feature
large-core laminated-iron inductors for low distortion and high power handling, to
ensure the very highest sound quality
Terminal Panel Bi-wirable. Can be single or double wired by removing shorting links provided
Internal wiring Solid–core copper cable
Cabinet 18mm MDF wrap and front baffle, extensively braced internally
Finish Cherry or Black Oak real-wood veneer.
Grilles Removable 'audiophile' grille fitted as standard
Alternative cloth-covered grilles are packed as accessories
Size - HxWxD - mm / in. 850 x 185 x 289 / 33.5 x 8.3 x 11.4 (cabinet only)
915x265x330 (inc. plinth and spikes)
Weight 16.9kg/37.2 lb net (single speaker including plinth)
15.5kg / 34.1 lb net (single speaker without plinth) 21.0kg / 46.2 lb gross per carton
Packaged One loudspeaker per carton
Power Handling 200 Watts unclipped speech and music
Frequency Range 44 Hz - 25 kHz
Impedance 4 Ohm nominal
Sensitivity 93dB /2.83V@1m
Amplifier Compatibility 10 - 200 Watts
Positioning Not less than 10 cm (4”) from rear wall
Tweeter Epos 25mm soft dome with high-temperature voice coil, ferrofluid cooling and
neodymium magnet system. Magnetically shielded
Bass/and Bass/Midrange Drivers 2x Epos 187mm dia., with cast chassis, 25mm high-temperature voice coil and
polypropylene cone
Crossover Frequencies 3.2kHz and 800Hz
nd
Crossover Bass, mid bass and tweeter networks all use 2 order filters. Only metal oxide resistors
and polypropylene film capacitors are used for optimum sound quality. The tweeter
section has an air-cored inductor. Both the woofer and mid-woofer sections feature
large-core laminated-iron inductors for low distortion and high power handling, all to
ensure the very highest sound quality
Terminal Panel Bi-wirable. Can be single or double wired by removing shorting links provided
Internal wiring Solid–core copper cable
Cabinet 18mm MDF wrap and front baffle, extensively braced internally
Finish Cherry or Black Oak real-wood veneer
Grilles Removable 'audiophile' grille fitted as standard.
Alternative cloth-covered grilles are packed as accessories.
Size - HxWxD - mm / in. 915 x 210 x 320 / 36 x 8.3 x 12.6 (cabinet only)
980x286x380 (inc. plinth and spikes)
Weight 20.8 kg / 45.8 lb net (single speaker including plinth)
19.1kg / 42 lb net (single speaker without plinth) 25.7 kg / 56.5 lb gross per carton
Packaged One loudspeaker per carton.
