Page Seven
Power Handling 100 Watts unclipped speech and music
Frequency Range 51 Hz - 25 kHz
Impedance 4 Ohm nominal
Sensitivity 89dB/2.83V@1m
Amplifier Compatibility 25 - 100 Watts
Positioning Not less than 10 cm (4”) from rear wall
Tweeter Epos 25mm soft dome with high-temperature voice coil, ferrofluid cooling and
neodymium magnet system. Magnetically shielded
Bass/Midrange Driver Epos mid bass 156mm dia., with cast chassis, 25mm high-temperature voice coil and
polypropylene cone. Magnetically shielded
Crossover Frequency 3.2kHz.
Crossover Bass and tweeter networks both use 2nd order filters. Only metal oxide resistors and
polypropylene film capacitors are used for optimum sound quality. The tweeter section
has an air-cored inductor, and the woofer section features a large-core laminated-iron
inductor for low distortion and high power handling, all to ensure the very highest sound
quality.
Terminal Panel Bi-wirable. Can be single or double wired by removing shorting links provided.
Internal wiring Solid-core copper cable.
Cabinet 18mm MDF wrap and front baffle, extensively braced internally
Finish Cherry or Black Oak real-wood veneer
Grilles Removable 'audiophile' grille fitted as standard,
Alternative cloth-covered grilles are packed as accessories
Size - HxWxD - mm / in.
Weight
Packaged One pair per carton
Grilles
310 x 185 x 245 / 12.2 x 7.2 x 9.7
6.1 kg / 13.4 lb net per single speaker
15.4 kg / 33.9 lb gross per carton
E&OE
Power Handling 120 Watts unclipped speech and music
Frequency Range 47 Hz - 25 kHz
Impedance 4 Ohm nominal
Sensitivity 90dB /2.83V@1m
Amplifier Compatibility 20 - 120 Watts
Positioning Not less than 10 cm (4”) from rear wall
Tweeter Epos 25mm soft dome with high-temperature voice coil, ferrofluid cooling and
neodymium magnet system. Magnetically shielded
Bass/Midrange Driver Epos 187mm dia., with cast chassis, 25mm high-temperature voice coil and
polypropylene cone. Magnetically shielded
Crossover Frequency 3.2kHz
Crossover Bass and tweeter networks both use 2nd order filters. Only metal oxide resistors and
polypropylene film capacitors are used for optimum sound quality. The tweeter section
has an air-cored inductor, and the woofer section features a large-core laminated-iron
inductor for low distortion and high power handling, all to ensure the very highest
sound quality.
Terminal Panel Bi-wirable. Can be single or double wired by removing shorting links provided.
Internal wiring Solid-core copper cable.
Cabinet 18mm MDF wrap and front baffle, extensively braced internally
Finish Cherry or Black Oak real-wood veneer
Grilles Removable 'audiophile' grille fitted as standard,
Alternative cloth-covered grilles are packed as accessories
Size - HxWxD - mm / in. 415 x 210 x 280 / 16.4 x 8.3 x 11
Weight 8.8 kg / 19.4 lb net per single speaker
21 kg / 46.2 lb gross per carton
Packaged One pair per carton
