SPECIFICATIONS
Power Handling 200 Watts maximum amplifier power
Frequency Range 48 Hz - 20 kHz
Impedance 4 Ohm nominal
Sensitivity 88dB/2.83V@1m
Amplifier Compatibility 50 - 200 Watts
Positioning Not less than 20 cm (8”) from rear wall
Tweeter Epos 25mm aluminium dome with high-temperature voice coil, ferrofluid cooling and
ferrite magnet system. Magnetically shielded
Mid/Bass Driver Epos Mid Bass 140mm with injection-moulded polymer cone and high-temperature
voice coil, mounted on a die-cast chassis with phase plug. Magnetically shielded
Bass Driver Epos Bass 140mm with injection-moulded polymer cone and high-temperature voice
coil, mounted on a die-cast chassis with dust cap. Magnetically shielded
Crossover Multi-element medium-order, at 150 Hz and 3 kHz. Tweeter has four components in a
3rd order filter at 3 kHz crossover, using film-caps throughout and a metal oxide
resistor.
Terminal Panel Tri-wirable.Can be single, bi-wired or tri-wired, using shorting links provided.
Internal wiring Mid-treble:0.8mm solid-core cabled. Bass: 1.2mm solid core. All low-oxygen copper
Cabinet 18mm MDF wrap and 25mm MDF front baffle, internally braced, with real wood finish
Finish Cherry, Red Cherry, Black Oak veneer
Size - HxWxD - mm / ins 885 x 174 x 210 / 35.8 x 6.9 x 8.3 without grille - including plinth but without spikes
Packaged One speaker and plinth per carton
Weight 16 kg / 35.3 lb per single speaker
21 kg / 46.3 lb per carton
Power Handling 100 Watt maximum amplifier power
Frequency Range 60 Hz - 20 kHz
Impedance 8 Ohm nominal
Sensitivity 87dB/2.83V@1m
Amplifier Compatibility 25 - 100 Watts
Positioning Either above or below the CRT or Plasma monitor. If close to the floor, angle the
speaker up a little to aim at listener’s face
Tweeter Epos 25mm aluminium dome with high-temperature voice coil, ferrofluid cooling and
ferrite magnet system. Magnetically shielded
Bass/Midrange Driver Epos 140m nominal, with 25mm high-temperature voice coil and injection-moulded
PP cone mounted on an inert die-cast aluminium chassis. Injection-moulded phase
plug. Magnetically shielded
Crossover Bass driver crossover by four components in a 2nd order filter. Tweeter has four
components in a 3rd order filter at 3 kHz crossover, using film-caps throughout and a
metal oxide resistor.
Terminal Panel Bi-wirable
Internal wiring 0.8mm solid-core cable. Low-oxygen copper
Cabinet 18mm MDF wrap and 25mm MDF front baffle internally braced, with real wood finish
Finish Cherry, Red Cherry, Black Oak veneer
Size - HxWxD - mm / ins 180 x 510 x 220 / 7.1 x 20 x 8.7 (without grille or plinth)
Packaged One centre channel and plinth per carton
Weight 10.8 kg / 22.8 lb per single speaker including plinth
13 kg / 28.7 lb per carton
