SPECIFICATIONS
Power Handling 300 Watts maximum amplifier power
Frequency Range 38 Hz - 20 kHz
Impedance 6 Ohm nominal
Sensitivity 87dB/2.83V@1m
Amplifier Compatibility 50 - 300 Watt into 6 Ohms
Positioning Not less than 20 cm (8”) from rear wall
Tweeter Epos 25mm aluminium dome with high-temperature voice coil, ferrofluid cooling and
ferrite magnet system. Magnetically shielded
Mid/Bass Driver Epos Mid Bass 165mm with polymer cone,32mm high-temperature voice coil and
injection moulded phase plug mounted on a die-cast chassis. Magnetically shielded
Bass Driver Epos Bass 165mm with polymer cone, 32mm high-temperature voice coil and
weighted injection moulded dust cap. Die-cast chassis. Magnetically shielded
Crossover Mid bass driver crossover is by mechanical design and without electrical network. 6 dB
on bass driver. Tweeter is AC coupled via polypropylene capacitor and metal oxide
resistor, 6 dB per octave, at 5 kHz.
Terminal Panel Tri-wirable. Can be single, double, or tri-wired by using shorting links provided
Internal wiring Mid-treble:0.8mm solid-core cable. Bass: 1.2mm solid core. All low-oxygen copper
Cabinet 18mm MDF wrap and 25mm MDF front baffle, internally braced, with real wood finish
Finish Cherry, Red Cherry, Black Oak veneer
Size - HxWxD - mm / ins 900 x 184 x 250 / 35.4 x 7.25 x 9.8 without grille - including plinth but without spikes
Packaged One speaker and plinth per carton
Weight 19.3 kg / 42.5 lb per single speaker
25 kg / 55 lb per carton
WARRANTY
WITHIN U.K.
Your Epos Mi series loudspeakers have been built to very high standards and should give many years of trouble free
service.
If, within five years of purchase, they prove to be defective for any reason other than accident, misuse, neglect,
unauthorized modification or fair wear and tear, we will repair the defect or, at our option, replace the faulty speakers
without charge for parts, labour or return carriage.
Your purchase receipt should be retained as it may be required in the event that you need to claim warranty attention.
This warranty is applicable in the United Kingdom only and given in addition to your statutory rights.
OUTSIDE U.K.
Service enquiries in countries other than the United Kingdom should be addressed to the local Epos agent or distributor.
Warranties granted in these countries are entirely at the discretion of the agent or distributor.
Epos speaker systems are sold in more than 45 countries worldwide.
Detailed information on all Epos products can be found by visiting the Epos website. www.epos-acoustics.com
Epos Limited reserves the right to change the specification of any of its speakers without notice.
Page Seven
Please see the Epos website for the complete list of
international distributors together with all contact details. www.epos-acoustics.com
