STYLUS COLOR 640
Page 2
REF. PART NO. DESCRIPTION QTY
D4 2014230 DIODE 1
F1 X502036070 FUSE 1
IC1 2023322 MICRO CONTROLLER, TMP95C061BF 1
IC10 2024977 TIMER IC 1
IC11 2014681 EEPROM, AT93C46-10SC 1
IC14 2017973 HIC 1
IC2 2026760 GATE ARRAY 1
IC3 X630114030 IC SOCKET 1
IC5 2023181 D-RAM 1
IC7 2026633 HIC, H8D2813E 1
IC9 2024507 RESET IC, M62030FP 1
Q1 2019965 TRANSISTOR 1
Q7 1040157 HEAT SINK 1
Q7 2024208 TRANSISTOR 1
Q8 1040157 HEAT SINK 1
Q9 1040157 HEAT SINK 1
Q9 2024209 TRANSISTOR 1
R166 2006289 CHIP RESISTOR 1
R167 2006289 CHIP RESISTOR 1
R22 X193211012 CHIP RESISTOR 1
R53 X193211012 CHIP RESISTOR 1
R84 2024308 METAL FILM RESISTOR 1
R93 2024307 METAL FILM RESISTOR 1
300 2025775 BOARD ASSY., POWER SUPPLY 1
330 2023343 WIRE HARNESS 1
400 2006741 POWER CABLE, BS31303SA-SR-10A 1
401 2018028 HARNESS 1
450 2023066 BOARD ASSY., PANEL 1
500 2028550 PRINTER MECHANISM(ASP) M4L10-100 1
501 1040655 FRAME ASSY., LEFT 1
502 2028086 MOTOR ASSY., PF 1
503 1039368 SPUR GEAR, 23.2 1
504 1030453 COMBINATIONGEAR, 16, 40.8 1
505 1030343 FRAME, RIGHT 1
506 1040571 FRAME, TOP 1
507 1031323 MOTOR ASSY, CR 1
508 1040515 PUMP ASSY. 1
509 1042881 CAP ASSY. 1
510 1030345 FRAME, BOTTOM 1
511 1032969 SHEET, PROTECTION, HEAD 1
512 1030344 FRAME, FRONT 1
513 1030392 BUSHING, PARALLELISM ADJUST, LEFT 1
514 1030393 BUSHING, PARALLELISM ADJUST, RIGHT 1
515 1030417 PAPER GUIDE, REAR 1
516 1041663 ROLLER, PF 1
517 1030957 COMPRESSION SPRING, 5.85 1
518 1037093 BUSHING, 12, LEFT 1
519 1030454 LEVER, CHANGE 1
520 1030452 SPUR GEAR, 26.4 1
521 1030975 SPACER, C-RING 2
522 1032301 SCALLOP SPRING PIN-AW, 2X16, F/B 1
523 1030965 COMPRESSION SPRING, 0.9 1
524 1030402 SPUR GEAR, 67.2 1
525 1037094 SPACER, FASTEN, ROLLER, PF 1
526 1037095 SPACER, FASTEN, ROLLER, PF; B 1
