Page #76 background imageLoading...
Page #76 background image
Projecting a PC Free Presentation
76
To move back up a folder level on your device, highlight Back to
Top and press [Enter].
To view additional files in a folder, highlight Next Page or Previous
Page, and press [Enter], or press the [Page] up or down buttons on
the remote control.
c
To play back a movie, press the arrow buttons to highlight the file and
press [Enter].
a
If any file names are longer than the display area or include
unsupported symbols, the file names may be shortened or
changed only on the screen display.
If you want to play back all the movies in a folder in sequence,
select the Slideshow option at the bottom of the screen.
d
To stop movie playback, press the [Esc] button, highlight Exit, and
press [Enter].
You return to the file list screen.
e
Turn off the USB device, if necessary, and then disconnect the device
from the projector.
gg Related Links
"PC Free Display Options" p.76
"Connecting to a USB Device" p.29
PC Free Display Options
You can select these display options when using PC Free. To access this
screen, highlight Option at the bottom of the PC Free file list screen and press
[Enter].
Setting Options Description
Display Order Name Order Displays files in name order
Date Order Displays files in date order
Sort Order In Ascending Sorts files in first-to-last order
In Descending Sorts files in last-to-first order
Continuous Play On Displays a slide show continuously
Off Displays a slide show once
Screen Switching
Time
No Does not display the next file
automatically
1 Second to 60 Seconds Displays files for the selected time
and switches to the next file
automatically; high resolution images
may switch at a slightly slower rate

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-2250U and is the answer not in the manual?

Epson EB-2250U Specifications

General IconGeneral
Matrix size0.76 \
Matrix type3-panel (p-Si TFT active)
Number of colors1.07 billion colors
Native aspect ratio16:10
Projection distance1.5 - 9 m
Vertical scan range200 - 240 Hz
Projection technology3LCD
Contrast ratio (typical)15000:1
Screen size compatibility50 - 300 \
Projection distance (tele)0 - 9 m
Projection distance (wide)0 - 1.5 m
Projector native resolutionWUXGA (1920x1200)
Keystone correction, vertical-30 - 30 °
Keystone correction, horizontal-20 - 20 °
Projector brightness (economic mode)3800 ANSI lumens
PlacementCeiling, Desktop
Product typeStandard throw projector
Product colorWhite
Cable lock slotYes
Cable lock slot typeKensington
Built-in displayNo
Lamp power300 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)10000 h
Color modes (2D)Cinema, Dynamic
Video processing10 bit
Video color modesDynamic, Cinema, Presentation, sRGB, Blackboard, DICOM simulation mode
Analog signal format system-
FocusManual
Throw ratio1.38 - 2.28:1
Digital zoom1.6 x
Focal length range23 - 38.4 mm
Aperture range (F-F)1.5 - 2
Power sourceAC
AC input voltage220-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.5 W
Power consumption (typical)405 W
Power consumption (economy mode)323 W
Audio (L/R) in0
Composite video in1
Serial interface typeRS-232C
USB 2.0 ports quantity2
VGA (D-Sub) ports quantity3
Ethernet LAN data rates10, 100, 1000 Mbit/s
Noise level39 dB
Country of originPhilippines
Noise level (economic mode)29 dB
RMS rated power16 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Cables includedAC, HDMI
Bundled softwareEasyMP Monitor, EasyMP Multi PC Projection
Pallet width800 mm
Pallet height3500 mm
Pallet length1200 mm
Pallet weight0 g
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet40 pc(s)
Quantity per pallet (UK)50 pc(s)
Quantity per pallet layer4 pc(s)
Harmonized System (HS) code85286200
Quantity per pallet layer (UK)5 pc(s)
Sustainability certificatesTCO
Weight and Dimensions IconWeight and Dimensions
Depth291 mm
Width377 mm
Height110 mm
Weight4600 g
Package depth530 mm
Package width383 mm
Package height210 mm
Package weight6401 g
