Wireless Network Projection
91
c
Select Wireless LAN On as the Wireless Mode setting.
d
Select Network Configuration and press [Enter].
e
Select the Basic menu and press [Enter].
f
Select the basic options as necessary.
• Projector Name lets you enter a name up to 16 alphanumeric
characters long to identify the projector over the network.
• PJLink Password lets you enter a password up to 32 alphanumeric
characters long for using the PJLink protocol for projector control
(EB‑2247U/EB‑2142W/EB‑2042/EB‑990U/EB‑980W/EB‑970/EB‑109
W/EB‑108/EB‑107/EB‑W39/EB‑X39).
• Remote Password lets you enter a password up to 8 alphanumeric
characters long for accessing the projector using the Basic Control.
(User name is EPSONREMOTE; default password is guest.)
• Web Control Password lets you enter a password up to 8
alphanumeric characters long for accessing the projector over the
Web. (User name is EPSONWEB; default password is admin.)
• Moderator Password lets you enter a four-digit number password
for accessing the projector as a moderator using Epson iProjection.
(No password is set by default.)
• Projector Keyword lets you turn on a security password to prevent
access to the projector by anyone not in the room with it. You must
enter a displayed, randomized keyword from a computer using
Epson iProjection to access the projector and share the current
screen.
• Display Keyword lets you select whether to display a projector
keyword on the projected image when accessing the projector using
Epson iProjection.
• Display LAN Info. lets you set the display format for the projector's
network information.
a
Use the displayed keyboard to enter numbers and characters.
Press the arrow buttons on the remote control to highlight
characters and press [Enter] to select them.
