Connecting External Equipment
You can output images and audio by connecting an external monitor or speaker.
You can also output microphone audio from the projector's speaker by connecting a microphone.
A
When outputting images to an external monitor
Connect the external monitor to the projector's Monitor Out port using the cable supplied with the external monitor.
B
When outputting audio to an external speaker
Connect the external speaker to the projector's Audio Out port using a commercially available audio cable.
C
When outputting microphone audio (EB-955WH/EB-950WH/EB-965H/EB-945H/EB-940H/EB-98H/EB-97H only)
Connect the microphone to the projector's Mic port. When using a condenser microphone, set Plug-in Power to On.
s Extended - A/V Settings - Plug-in Power p.106
Connecting Equipment
33
