Epson EB-E10 User Manual

Copying Menu Settings Between Projectors (Batch Setup)
155
i
Connect the USB cable to the computer's USB port and to the
projector's USB-B port.
j
Hold down the [Menu] button on the remote control or the control
panel and connect the power cord to the projector.
k
When all of the projector's indicators turn on, release the [Menu]
button.
The computer recognizes the projector as a removable disk.
l
Copy the batch setup file (PJCONFDATA.bin) that you saved to your
computer to the top level folder of the removable disk.
a
Do not copy any files or folders other than the batch setup file to
the removable disk.
m
Eject the USB device (Windows) or drag the removable disk icon to the
Trash (Mac).
n
Disconnect the USB cable.
When all of the indicators start flashing, the settings are being written.
When writing is finished, the projector turns off.
Caution
Do not disconnect the power cord from the projector while the file is being
written. If the power cord is disconnected, the projector may not start
correctly.
gg Related Links
• "Batch Setup Error Notification" p.155
Batch Setup Error Notification
The projector's indicators notify you if an error occurs during a batch setup
operation. Check the status of the projector's indicators and follow the
instructions described in the table here.
Indicator status Problem and solutions
• Lamp: Orange - flashing
fast
• Temp: Orange - flashing
fast
The batch setup file may be corrupt, or the USB flash
drive or USB cable may not be connected correctly.
Disconnect the USB flash drive or the USB cable,
unplug and then plug in the projector's power cord, and
then try again.
• Power: Blue - flashing
fast
• Status: Blue - flashing
fast
• Lamp: Orange - flashing
fast
• Temp: Orange - flashing
fast
Writing the settings may have failed and an error may
have occurred in the projector's firmware.
Stop using the projector, remove the power plug from
the electrical outlet. Contact Epson for help.
gg Related Links
• "Projector Indicator Status" p.169

Epson EB-E10 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	0 - 1.76 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Screen size compatibility	22 - 350 \
Projection distance (wide)	0.87 - 10.34 m
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	2200 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Focus	Manual
Throw ratio	1.44 - 1.95:1
Fixed focal length	16.7 mm
Full HD	No
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
AC (power) in	Yes
Composite video in	0
HDMI connector type	Full-size
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
RMS rated power	2 W
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Housing material	Plastic
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Bundled software	Inhalt DIY-App, Epson Projektor Management, Epson Projektor Professional Tool
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
USB display function	2 in 1: Image / Mouse

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2400 g
Package depth	376 mm
Package width	327 mm
Package height	152 mm
Package weight	3716 g
