Attention
• When projecting with the projector tilted, do not tilt it at more than the
specified angle. This may cause malfunctions or accidents to occur.
Angle of tilt
Vertical: Can be installed at any angle in a complete 360 degrees.
90
45
0
135
180
-135
-90
-45
Horizontal: Can be tilted within the range of expansion and contraction for
the rear feet. The feet can be attached and removed. Note that the feet will
detach if they are extended more than 10 mm.
• Once installation is complete, make sure you set the Direction. Otherwise the
lamp's operating life may be reduced significantly.
s
"Setting the direction" p.26
• Using the projector at an improper angle or setting the Configuration menu
incorrectly causes malfunctions and shortens the operating life of optical
parts.
Attention
• Make sure there is a gap as shown in the following illustration between the
wall and the air exhaust vent and the air intake vent.
Air exhaust vent Air intake vent
• When setting up multiple projectors, make sure there is a gap of at least
50 cm between the projectors. Also, make sure that the heat from the air
exhaust vent does not go into the air intake vent.
• Do not place the projector directly on top of another projector.
• Do not project the image putting the projector longitudinally.
Safety Warning and Cautions
5
