EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480
Disassembly and Assembly CONFIDENTIAL
SEIKO EPSON 107 Revision C
3.5.2 Preparation
Obtain the following tools from the Tech Exchange in advance.
Note *1: (Definition file)
*2: Use the latest ones referring to “TI08-30e”.
3.5.3 Operating Procedure
3.5.3.1 Workflow
The whole replacing operation work flow is shown below.
Figure 3-43. Workflow for the replacement using DR data
Tool Name Remark
CAT (IRIS/CAT)*
1
Install it in your PC.
“IRIS_MENT.zip” file*
2
Save this file to the specified folder.
Model Group List*
2
Necessary for selecting the current model on the CAT, and
also for preparing the correct ASP for the projector to be
repaired.
In the following procedure, refer to the “CAT Operation Manual”
published as the technical information TI08-30e for more detailed
operation procedures of CAT.
START
END END
"3.5.3.2 Check in advance" (p.108)
"3.5.3.3 Replacing the Optical
Engine" (p.110)
"3.5.3.4 Replacing the MA Board"
(p.112)
