Projector Feature Settings - Settings Menu
132
Options on the Settings menu let you customize various projector features.
Setting Options Description
E-Zoom Varying levels
available
Adjusts the size of the projected image.
Keystone Adjusts image shape to rectangular
(horizontally and vertically).
H/V-Keystone H/V-Keystone: Select to manually
correct horizontal and vertical sides.
Auto V-Keystone: Turns automatic
correction on or off. (Available only for
models that support the Auto V-
Keystone function.)
H-Keystone Adjuster: Turns H-
Keystone Adjuster on or off. (Available
only for models that have the horizontal
keystone slider.)
Quick Corner Quick Corner: Select to correct image
shape and alignment using an on-screen
display.
Setting Options Description
Split Screen Screen Size
Source
Swap Screens
Audio Source
Align
Display the QR
Code
Exit Split Screen
Divides the viewing area horizontally and
displays two images side-by-side (press
[Esc] to cancel split screen display).
Volume Varying levels
available
Adjusts the volume of projector’s speaker
system.
You can also adjust the volume of
external speakers.
Setting values are saved for each source.
Mic Input Level Varying levels
available
Adjusts the input level from a
microphone.
When Mic Input Level is turned up, the
volume of the other connected device is
turned down; when it is turned down,
the volume of the other connected device
is turned up.
(Available only for models that have the
Mic port.)
Lock Setting Control Panel Lock Controls projector button locking to
secure the projector:
Full Lock: locks all buttons.
Partial Lock: locks all buttons except the
power button.
Off: no buttons locked.
Remote Receiver Front/Rear
Front
Rear
Off
Limits reception of remote control
signals by the selected receiver; Off turns
off all receivers.
Options vary depending on the number
of remote receivers equipped on the
projector.

Table of Contents

Other manuals for Epson EB-X51

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-X51 and is the answer not in the manual?

Epson EB-X51 Specifications

General IconGeneral
Matrix size0.55 \
Number of colors1.07 billion colors
Native aspect ratio4:3
Projection distance1.8 - 2.17 m
Vertical scan range100 - 120 Hz
Projection technology3LCD
Contrast ratio (typical)16000:1
Screen size compatibility30 - 300 \
Projector native resolutionXGA (1024x768)
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)2500 ANSI lumens
RMS rated power2 W
Number of built-in speakers1
PlacementCeiling, Desktop
Product typeStandard throw projector
Product colorWhite
Market positioningPortable
Cable lock slot typeKensington
Lamp typeUHE
Lamp power210 W
Light source typeLamp
Service life of light source6000 h
Service life of light source (economic mode)12000 h
Built-in displayNo
FocusManual
Offset8 %
Throw ratio1.48 - 1.77:1
Focal length range16.9 - 20.28 mm
Aperture range (F-F)1.49 - 1.79
Power sourceAC
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)327 W
Power consumption (economy mode)225 W
Video color modesBlackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system-
USB 2.0 ports quantity2
Noise level37 dB
Country of originPhilippines
Noise level (economic mode)28 dB
Cables includedAC, VGA
Bundled softwareInhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function2 in 1: Image / Mouse
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Pallet weight0 g
Quantity per pack1 pc(s)
Quantity per pallet84 pc(s)
Quantity per pallet (UK)126 pc(s)
Harmonized System (HS) code85286200
Weight and Dimensions IconWeight and Dimensions
Depth237 mm
Width302 mm
Height82 mm
Weight2500 g
Package depth380 mm
Package width335 mm
Package height150 mm
Package weight4035 g
