Epson M200 Series User Manual

Confidential
Disassembly/Reassembly Overview 24
M200 / M205 / M100 / M105 Series Revision A
Housing Ink Supply Tank 1:32 1:32
ADF/SCN Unit 2:46 2:52 5:38
ADF Unit
3:32 2:52 6:24
ADF Hinge Left 5:28 5:28
ADF Document Support
7:06 7:06
ADF Hinge Right 3:53 3:53
Cover Gear Assy 4:29 4:29
Bevel Gear Shaft
4:34 4:34
Combination Gear 24.9.6 4:33 4:33
ADF Frame Assy 5:04 5:04
ADF Front Frame 6:00 6:00
Spur Gear 20.4 / 25.8 6:04 6:04
ADF Driven Gears 6:42 6:42
ADF Upper Frame Assy 6:44 6:44
ADF Pad Assy
7:23 7:23
ADF Base Assy 6:15 6:15
Scanner Unit
3:30 2:52 6:22
Scanner Housing Upper 5:05 5:05
CIS Module Unit 5:28 5:28
Spacer 5:44 5:44
CIS Module 5:44 5:44
Scanner Motor Gear Cover 5:58 5:58
Combination Gear 18.4.9.66 6:05 6:05
Scanner Carriage Unit 6:09 6:09
Scanner Motor 8:25 8:25
CIS Holder Unit 8:25 8:25
Scanner Housing Lower 6:09 6:09
Housing Left
4:19 4:19
Ethernet Cover 4:25 4:25
Panel FFC Cover
3:04 3:04
Hinge 3:02 3:02
Housing Right 5:32 5:32
Strengthen Plate Upper 4:09 4:09
Strengthen Plate Lower 4:10 4:10
Cap Assy
5:06 5:06
Cap Lever 5:15 5:15
Porous Pad for Cap Assy
5:21 5:21
Star Wheel Holder Assy 1:52 3:18 5:10
EJ Roller 3:48 3:18 7:04
Panel Unit 5:27 5:27
Panel Housing Upper Assy 6:01 6:01
Panel Board 7:33 7:33
Panel Button 9:04 9:04
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total

Epson M200 Series Specifications

General

Print Technology	Inkjet
Print Resolution	1440 x 720 dpi
Scanner Type	Flatbed color image scanner
Scan Resolution	1200 x 2400 dpi
Functions	Print, Scan, Copy
Ink Colors	Black
Print Speed (Black)	34 ppm
Connectivity	USB 2.0, Ethernet
Paper Sizes	A4, A5, A6, B5
Operating Systems	Windows XP / XP Professional x64 Edition / Vista / 7 / 8 / 8.1
