Epson M200 Series User Manual

Confidential
Adjustment Required Adjustments 62
M200 / M205 / M100 / M105 Series Revision A
Part Name
LD Roller Assy
Remove
--- --- ---
Replace
--- --- ---
CR Motor
Remove
--- --- ---
Replace
--- --- ---
PE Sensor Lever
Remove
--- --- ---
Replace
--- --- ---
Main Board
Remove
--- --- ---
Replace (Read OK)
--- --- ---
Replace (Read NG)
--- --- ---
CR Driven Pulley
Remove
--- --- ---
Replace
--- O ---
Main Frame Assy
Remove
--- --- ---
Replace
OO---
Paper Guide Upper Assy
Remove
--- --- ---
Replace
--- --- ---
CR Unit
Remove
--- --- ---
Replace
O --- ---
CR Timing Belt
Remove
--- --- ---
Replace
--- O ---
Frame Base Assy Replace
--- --- O
PF Roller Unit
Remove
--- --- O
Replace
--- --- O
PF Motor Assy
Remove
--- --- O
Replace
--- --- O
Frame Base Replace
--- --- O
Table 3-1. Required Adjustment List
Adjustment Type Mechanism adjustment
Priority
1 2 3
Adjustment Item
Checking the Platen
Gap
CR Belt tension check PF Belt tension check
Purpose
Check if the PG is within
the standard.
Check the tension of the
CR Timing Belt
Check the tension of the
PF Timing Belt
Printout pattern
--- --- ---
How to judge
See " 3.3.1 Checking the
Platen Gap (p69)" for
the details.
See " 3.3.2 CR/PF Belt
Tension Check (p71)"
for the details.
See " 3.3.2 CR/PF Belt
Tension Check (p71)"
for the details.
Adjustment program
--- --- ---
Tool See p69 See p71 See p71
Note "*1":Necessary when the part is replaced at a point in the disassembly procedures other than specified in this manual.

Epson M200 Series Specifications

General

Print Technology	Inkjet
Print Resolution	1440 x 720 dpi
Scanner Type	Flatbed color image scanner
Scan Resolution	1200 x 2400 dpi
Functions	Print, Scan, Copy
Ink Colors	Black
Print Speed (Black)	34 ppm
Connectivity	USB 2.0, Ethernet
Paper Sizes	A4, A5, A6, B5
Operating Systems	Windows XP / XP Professional x64 Edition / Vista / 7 / 8 / 8.1
