Appendix Protection for Transportation 85
M200 / M205 / M100 / M105 Series Revision A

Singlefunction Printer
Attach the strong tape (3 tapes) to the position on the following diagram and secure the Paper Support/
Paper Support Sub on the Housing Upper Assy.
Figure 5-4. Securing the Paper Support/Paper Support Sub (Singlefunction Printer)
Rear
Paper Support/ Paper
Support Sub
Folded ends
Paper Support/ Paper
Support Sub
Strong tape
