Epson PowerLite 84 Installation Handbook

INSTALLATION
HANDBOOK
Lamp and Status Information
Epson PowerLite 84
9. Once the lamp is fully inserted, tighten its screws.
10. Replace the lamp cover, then tighten its screw.
11. Reset the lamp timer as described page.
Resetting the Lamp Timer
After you replace the lamp, you need to reset the lamp timer using the
projector’s menus.
1. Press the
Menu button on the remote control or on the
projector’s control panel. You see the main menu.
2. Use the buttons on the remote control (or the arrow buttons
on the projector) to highlight
Reset, then press Enter.
You see this screen:
3. Select
Reset Lamp Hours and press Enter.
4. When you see the prompt, select
Yes and press Enter.
5. When you’re nished, press
Esc or Menu to exit the Menu
system.

Epson PowerLite 84 Specifications

General

Projection technology	LCD
Contrast ratio (typical)	2000:1
Projector native resolution	XGA (1024x768)
Aspect ratio	4:3
Dimensions (WxDxH)	327.6 x 248.9 x 93.9 mm
Power requirements	100-240VAC +/-10%, 50/60Hz AC
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
Focal length range	18.2 - 29.2 mm
RMS rated power	10 W
Number of built-in speakers	1
Microphone in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	2
Power consumption (typical)	289 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	3100 g
