EpsonAmerica,Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
EpsonCanadaLimited
185 Renfrew Drive, Markham, Ontario L3R 6G3
www.epson.com
www.epson.ca
PowerLiteW163DWXGA3LCDProjector
Product Name Product Code UPC
PowerLite W16 Projector V11H493020 0 10343 90401 9
Genuine Epson Lamp V13H010L67 0 10343 88423 6
Replacement Air Filter V13H134A42 0 10343 90405 7
Specifications
Projection System
Epson 3LCD, 3-chip technology,
RGB liquid crystal shutter projection system
Projection Method
Front / Rear / Ceiling mount
Driving Method
Poly-silicon TFT Active Matrix
Pixel Number
1,024,000 dots (1280 x 800) x 3
Color Brightness
2
Color Light Output: 3000 lumens in 2D mode
White Brightness
2
White Light Output: 3000 lumens in 2D mode
Aspect Ratio
Native 16:10 widescreen, supports 16:9/4:3
Native Resolution
1280 x 800 (WXGA)
Resize
640 x 480 (VGA), 800 x 600 (SVGA),
1024 x 768 (XGA), 1152 x 864 (SXGA),
1280 x 960 (SXGA2), 1280 x 1024 (SXGA3),
1360 x 768 (WXGA 60-2), 1440 x 900 (WXGA+),
1400 x 1050 (SXGA+), 1600 x 900 (WXGA++),
1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+ 60)
Lamp Type
200 W UHE (E-TORL)
Lamp Life
5
Up to 5000 hours (ECO mode)
Up to 4000 hours (Normal mode)
Throw Ratio Range
1.30 – 1.56
Size (projected distance)
33" – 318"
Keystone Correction (Automatic)
Vertical: ± 30 degrees
Horizontal: ± 20 degrees
Mac Connectivity
Projector is Mac compatible via USB,
DVI to HDMI or VGA adapter (not included)
Contrast Ratio
Up to 5000:1 (2D)
Up to 3000:1 (Active 3D)
Color Reproduction
Full-color (16.77 million colors)
Specifications (continued)
Built-in 3D Emitter
RF Type, distance within 32.8'
3D Format
Auto/Side-by-Side/Top-and-Bottom/2D/
Frame Packing
Projection Lens
Type
Manual Focus / Manual Optical Zoom
F-number
1.58 – 1.72
Focal Length
16.9 – 20.3 mm
Zoom Ratio
1.0 – 1.2 Optical
Lens Cover
Slide lens shutter (A/V Mute slide)
Other
Display Performance
NTSC: 480 lines
PAL: 560 lines
(Depends on observation of the
multi-burst pattern)
Input Signal
NTSC/NTSC4.43/ PAL/M-PAL/N-PAL/
PAL60/SECAM
Interfaces
Computer: D-sub 15 pin x 2
Component video: D-sub 15 pin x 1
(shared with Computer 1)
S-video: Mini DIN x 1
Composite video: RCA (Yellow) x 1
Audio in: RCA x 1 (L and R)
USB connector: Type B x 1
(USB display, audio and mouse control)
USB connector: Type A x 1
(USB memory/document camera)
HDMI x 1
Serial: RS-232c x 1
Monitor out: D-sub 15 pin x 1
(shared with Computer 2)
Audio out: Mini stereo x 1
Other (continued)
Speaker
2 W Monaural
Standby Audio
Through Audio Out only
Operating Temperature
5 °C to 35 °C (41 °F to 95 °F)
Power Supply Voltage
100 – 240 V AC, ±10%, 50/60 Hz
Power Consumption
237 W (ECO Mode)
289 W (Normal Mode)
3.2 W Standby (Communication On)
0.36 W Standby (Communication Off)
Fan Noise
29 dB (ECO Mode)
36 dB (Normal Mode)
Security
Kensington
®
Security Lock Port, Padlock,
Security Cable Hole and Password
Protect Function
Dimensions (W x D x H)
Including feet: 12.8" x 9.6" x 3.1"
Excluding feet: 12.8" x 9.6" x 3.0"
Weight: 6.0 lb
Remote Control
Features
Source search, video, computer, USB, power,
aspect, color mode, volume, e-zoom, A/V mute,
freeze, menu, page up and down, help, auto,
mouse functions, user, esc, screen fit,
2D/3D, pointer
Operating Angle
Right/left: ± 30 degrees
Upper/lower: ± 15 degrees
Operating Distance
19.7' (6 m)
Support
The Epson Connection
SM
Pre-sales support
U.S. and Canada 800-463-7766
Internet website www.epson.com
Service Programs
Two-year projector limited warranty,
Epson Road Service program, PrivateLine
®
dedicated toll-free support and 90-day limited
lamp warranty
What’s In The Box
PowerLite W16 3D WXGA 3LCD projector, power
cord, VGA cable, remote control with 2 AA
batteries, quick setup guide and user’s guide CD
Accessory Part Numbers
Genuine Epson lamp (ELPLP67) V13H010L67
Replacement air filter (ELPAF42) V13H134A42
Active Shutter RF 3D glasses
(ELPGS03) V12H548006
Active speakers (ELPSP02) V12H467020
Epson DC-06 document camera V12H321005
Epson DC-11 document camera V12H377020
Epson DC-20 document camera V12H500020
Universal projector ceiling mount ELPMBPJF
Adjustable suspended ceiling
channel kit ELPMBP01
False ceiling plate kit ELPMBP02
Structural round ceiling plate ELPMBP03
Adjustable extension column
(pipe) 8"-11" ELPMBC01
Component to VGA cable ELPKC19
Kensington security lock ELPSL01
Duet™ screen ELPSC80
ES3000 portable screen
(ELPSC26H) V12H002S3Y
PowerLite
®
W16 3D WXGA 3LCD Projector
