Epson Stylus D88 User Manual

2
Setting up CorelDRAW 10 onwards
Diagram 2
Before you start this section you will need to download the Xpres Subli-Print colour profile from the Xpres website.
The address is www.xpres.co.uk/technical.php You can also find the profile on the Subli-Print CD supplied with the bulk
feed system. This disk can also be sent out upon request.
Close CorelDRAW. When you have downloaded the 'Subli_Print_D88_V1.icm' colour profile, right click on it and
choose 'Install Profile' from the top of the menu. Note: The profile will install automatically and will not give any feedback.
Also on some systems you will not be able to see the 'Install Profile' option. If this is the case change the .ICM extension
to .ICC then re-try.
Start CorelDRAW and click on Window > Colour Palettes. Tick the 'Default RGB palette'. Repeat the process then
un-tick 'Default CMYK palette'. Now click on Tools > Colour Management. You will now see the colour management
dialogue box appear as in diagram 1 below.
Note: For CorelDRAW X3 users
click on 'RGB (used in versions
previous to CorelDRAW X3', under
the 'Colour mode used for effects'
section at the bottom.
First, all the (Orange/Grey) arrows need to be set as shown above. To change the colour of the
arrows (Orange colour switched on, Gray colour switched off). To turn the arrows on or off just click
on the arrow itself.
Configure Import-Export Settings: Click on the image of the paper to bring up the window shown
below (diagram 2). This window configures how CorelDRAW handles files that are imported to a
document.
Composite Printer: Select the Subli_Print_D88_V1 printer profile. Note: if you cant choose the
Subli_Print_D88_V1 from the drop down menu means the ICC profile is not yet installed on your
pc or you may not have restarted Corel since the ICC installation. Close and re-launch Corel.
1.
2.
Click Import: Always covert Using- Select Internal RGB Fraser
(1998) from the drop down menu.
Click Export: Always embed using- Select Internal RGB Fraser
(1998) from the drop down menu.
Click OK.
Diagram 1
1
2
3
5
4

Epson Stylus D88 Specifications

General

Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	22 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
I/O ports	USB 1.1 Parallel
Maximum print size	210 x 297 mm
Standard media sizes	DIN A4
Maximum ISO A-series paper size	A4
Color	Yes
Print head nozzles	180 nozzles for Black, 59 nozzles per Cyan, Magenta, Yellow
Number of print cartridges	4
Package depth	540 mm
Package width	320 mm
Package height	255 mm
Package weight	5800 g
Bundled software	Epson Creativity Suite
Quantity per pack	1 pc(s)
Interface	Parallel, USB 2.0 Type B
Dimensions (WxDxH)	460 x 242 x 198 mm
Media types supported	Premium Ink Jet Plain Paper A4, Bright White Ink Jet Paper A4, Premium Glossy Photo Paper A4, 13 x 18cm (5 x 7\
Minimum system requirements	Windows: Pentium 1.0GHz+, 256MB RAM, 550MB Mac OS: Power PC G4 700MHz+, 256MB RAM 2.1GB
Compatible operating systems	Windows 98SE / Me / 2000 / XP, Mac OS 9+
Sound power level (printing)	42 dB
Sustainability certificates	ENERGY STAR
Power consumption (printing)	11 W
Country of origin	Japan
Market positioning	Home & office
Pallet width	800 mm
Pallet height	2190 mm
Pallet length	1200 mm
Pallet weight	210.6 g
Pallet width (UK)	1000 mm
Pallet weight (UK)	303400 g
Quantity per pallet	32 pc(s)
Quantity per pallet (UK)	48 pc(s)
Quantity per pallet layer	4 pc(s)
Quantity per pallet layer (UK)	6 pc(s)

Weight and Dimensions

Depth	242 mm
Width	460 mm
Height	198 mm
