EQUATION EQH-70 - Technical Data

30
VIII.- TECHNICAL DATA.
WARNING! Your EQH built-in fireplace should not be used as an incinerator
and no other types of fuel should be used (plastic, coal…). Use
recommended materials only.
Recommended fuel:
Dimensiones L x Ø (approx)
FUEL
EQH-70
EQH-80
Haya
50cm x 7cm
60cm x 7cm
Encina
50cm x 7cm
60cm x 7cm
Pino
50cm x 7cm
60cm x 7cm
Draw = 2 mmca.
(*) In the case of other heights consult your Dealer or the manufacturer
Model: EQH-70 Built-in Fireplace.
Maximum Power. LOG (Oak, beechwood…)
13,72KW
Power transmitted to the atmosphere (useful)
10,5KW
Mass of fuel / hour
3,2 kg
Average gas temperature
307 ºC
Average CO concentration at 13% O2
0,16
Performance
76.5%
Accepts logs of the following length:
520 mm.
Fumes ring
175 mm.
Metal Chimney
175 mm.
Recommended chimney height
5 to 6 metres
Brickwork chimney, at least (approx.)
200 x 200 mm.
Smoke outlet
Vertical
Minimum draw recommended
12 Pa
Primary Air Control
Manual regulation
Weight
141 kg
Model: EQH-80 Built-in Fireplace.
Maximum Power. LOG (Oak, beechwood…)
17,34 KW
Power transmitted to the atmosphere (useful)
13,2 KW
Mass of fuel / hour
3,9 Kg
Average gas temperature
331 ºC
Average CO concentration at 13% O2
0,16
Performance
76,1%
Accepts logs of the following length:
620 mm.
Fumes ring
200 mm.
Metal Chimney
200 mm.
Recommended chimney height
5 to 6 metres
Brickwork chimney, at least (approx.)
250 x 250 mm.
Smoke outlet
Vertical
Minimum draw recommended
12 Pa
Primary Air Control
Manual regulation
Weight
147 kg
