Equinox Systems EQLED032 - Page 3

www.prolight.co.uk RGB Power Batten User Manual
3
Product overview & technical specications
The1mRGBPowerBattencontains240RGBLEDsdividedinto8segments.Onboardfeaturesincludecolour
mixingtocreatesoftwashesfromitsrichcolourpalette,andchaseprogramscontrolledinautomodeoractivated
bymusic.Severaldifferentchaseprogramsareincludedandcanbeselectedbythecontrolpanelalongwith
brightnessandspeed.
•240x10mmLEDs(R:96,G:72,B:72)
•Beamangle:30°
•DMXchannels:2/3/4/7/14or26selectable
•Soundactive,autoandmaster/slavemodes
•0-100%dimmingandvariablestrobe
•Bracketallowsformultipleriggingoroor
standingapplications
•4pushbuttonmenuwithLEDdisplay
•IECpowerinput/output
•3-PinXLRinput/output
•Convectioncooled
RGB Power Batten
Specications
Powerconsumption 30W
Powersupply 100~240V,50/60Hz
Fuse T1A250V
Dimensions 85x1075x65mm
Weight 1.8kg
Ordercode EQLED032
0m 1m 2m 3m 4m 5m
30° - Lux 2960 741 329
30°
185 119
1075mm 65mm
85mm
