Equinox Systems EQLED032 - Master;Slave Mode

www.prolight.co.uk RGB Power Batten User Manual
8
Auto mode:
Toaccessautomode,pressthe“MENU”buttononthefrontoftheunittoshowAutoontheLED
display.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoosetherequired
programn001~n100.Pressthe“ENTER”buttonthenusethe“UP”and“DOWN”buttonstoselect
therunningspeedSP01~SPFL.Pressthe“ENTER”buttonagainandusethe“UP”and“DOWN”
buttonstoselectthefadingtimeFd00~Fd99.Finallypressthe“ENTER”buttonandusethe“UP”
and“DOWN”buttonstoselecttheashspeedF500~F599.
Pressthe“ENTER”buttontoconrmthesetting.
Master/slave mode:
ThedefaultsettingforthisxtureisMaster.
Tosettheslaveunit,pressthe“MENU”buttononthefrontofthemasterunittoshowSLav
ontheLEDdisplay.TheunitisnowinSlavemode.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
PleaseensurethatallslaveunitsaresettothesameDMXchannelmodeasthemasterunit.
Sound active mode:
Toaccessthesoundactivemode,pressthe“MENU”buttononthefrontoftheunittoshowSU31
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstosetthe
soundsensitivity01~31.Pressthe“ENTER”buttontoconrmthesetting.
Value: 01 - 31 (01 = low sensitivity, 31 = high sensitivity)
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Operating instructions
26 channel mode:
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9
Segment1
Red
(0-255)
Segment1
Green
(0-255)
Segment1
Blue
(0-255)
Segment2
Red
(0-255)
Segment2
Green
(0-255)
Segment2
Blue
(0-255)
Segment3
Red
(0-255)
Segment3
Green
(0-255)
Segment3
Blue
(0-255)
CH19 CH20 CH21 CH22 CH23 CH24 CH25 CH26
Segment7
Red
(0-255)
Segment7
Green
(0-255)
Segment7
Blue
(0-255)
Segment8
Red
(0-255)
Segment8
Green
(0-255)
Segment8
Blue
(0-255)
Flash
(0-255)
Slow-fast
Master
dimmer
(0-255)
CH10 CH11 CH12 CH13 CH14 CH15 CH16 CH17 CH18
Segment4
Red
(0-255)
Segment4
Green
(0-255)
Segment4
Blue
(0-255)
Segment5
Red
(0-255)
Segment5
Green
(0-255)
Segment5
Blue
(0-255)
Segment6
Red
(0-255)
Segment6
Green
(0-255)
Segment6
Blue
(0-255)
