Erbauer EBPW2400 - Machine Description

Machine description
Safety instructions
Assembly
Use
Guarantee
Declaration of conformity
Care & maintenance
4
10
20
23
31
39
41
5063022018885-EBPW2400-PressureWasher-UM-V02.indd 25063022018885-EBPW2400-PressureWasher-UM-V02.indd 2 08-11-2022 16:26:3908-11-2022 16:26:39
WARNING! Please read all safety
warnings carefully and be sure that
they are fully understood before
handling the machine.
1
MACHINE DESCRIPTION
1. Transportation handle
2. Trigger gun holder
3. Lock-off button
4. Twin rotary nozzle
5. Supply cord holder (x2)
6. Supply cord with power plug
7. Accessories chamber
8. 5-in-1 nozzle
9. Foam cannon
a. Flow adjustment knob
b. Connection port
c. Nozzle
d. Detergent bottle
10. Wheel (x2)
11. Water inlet
12. On/off switch (O/ I)
13. High pressure hose
14. Hose reel
15. Crank handle
16. Extension lance
17. Trigger gun
a. Trigger lever
b. Hose connection
c. Pressure adjustment knob
d. Trigger lock lever
18. Water inlet hose adapter
a. Gasket
 b. Inletlter
19. Cleaning needle
20. Water outlet
21. Accessories holder (x2)
