Avoid using tools in temperatures of 10ºC or less. Plan your work
schedule to spread any high vibration tool use across a number of
days.
NOTE: The use of other tools will reduce the users’ total
working period on this tool.
HEALTH SURVEILLANCE
All employees should be part of an employer’s health surveillance
scheme to help identity any vibration related diseases at an early
stage, prevent disease progression and help employees stay in
work.
RESIDUAL RISKS
Even if you are operating this product in accordance with all
the safety requirements, potential risks of injury and damage
remain. The following dangers can arise in connection with
the structure and design of this product:
1. Injuries and damage to property due to broken attachments or
the sudden impact of hidden objects during use.
2. Danger of injury and property damage caused by ying objects
or poor power tool accessories.
PRODUCT DESCRIPTION
1. Keyless chuck
1a. Chuck jaws
1b. Chuck sleeve
2. Torque adjustment ring
3. Function selection ring
4. Two-speed gear control
5. Forward/reverse rotation control
6. Battery pack
7. Power bar button
8. Battery pack release button
9. LED work light
10. Belt clip
11. On/off switch
12. Handle
01
TECHNICAL SPECIFICATIONS
Drill
Rated voltage: 18V d.c.
Rated no load speed: 0-480/0-1700/min
Impact rate: 0-7200/0-25500/min
Clutch position:
Max. torque:
17+1+1
50 N.m
Chuck capacity:
Max. drilling capacity:
13mm
•
Wood 35mm
•
Steel 10mm
•
Masonry 13mm
Weight (without battery): 1.1 kg
Battery For
EAN. 3663602666219
EAN. 3663602799030
EAN. 3663602799801
For
EAN. 3663602798552
EAN. 3663602798569
Battery pack model: EBAT18-Li-2 EBAT18-Li-4
Battery voltage: 18V d.c. 18V d.c.
Battery capacity 2Ah 4Ah
Battery cell: Li-Ion 3.6V x 5pcs Li-Ion 3.6V x 10pcs
Weight: 0.4kg 0.7kg
Ambient temperature range for tool and battery use: -10
o
C to 40
o
C
For use with battery pack and charger as below:
Battery pack model: EBAT18-Li-2 / EBAT18-Li-4 / EBAT18-Li-5
Charger model: EC18-Li / EFC18-Li / EMC18-Li
