Product description
Part index
The index below refers to Fig. 1 on page 4.
1. Rebate depth gauge
a. Scale (in Fig. D)
2. Locking lever
3. Depth scale
4. Cutting depth adjustment knob
5. Dust extraction outlets (×2)
6. On/off switch
7. Lock-off button
8. Handle
9. Dust/Chip extraction guide switch
10. Mounting thread (parallel guide)
11. Blade protection foot
12. Rear plate
13. Front plate
14. V-groove
15. Air vents
16. Wrench
17. Hex bolts (×3)
18. Blade
19. Grub screws (×2)
20. Roller
21. Guard
22. Dust bag
23. Hex key 2.5mm
24. Parallel guide assembly
a. Wing screw*
b. Angle bracket*
c. Mounting bolt*
d. Wing nut*
e. Parallel guide*
Parts marked with * are not shown in this overview. Please refer to the
respective section in the instruction manual.
Symbols
On the product, the rating label and within these instructions you will nd among others
the following symbols and abbreviations. Familiarize yourself with them to reduce
hazards like personal injuries and damage to property.
Always wear eye protection. Always wear ear protection.
Wear a dust mask. Wear protective gloves.
Note / Remark. Unlock / to loosen.
Note / Remark. Caution / Warning.
