02
Bevel planing (Fig. H)
With the V-groove (14) bevel angles of 45° can be cut on the edge of a workpiece.
1. Place the V-groove (14) onto the edge of the workpiece. Apply slight consistent
pressure against the workpiece to achieve an even result.
2. Guide the product along the edge.
03
Rebate planing (Fig. I)
• Attach the parallel guide assembly (24) and rebate depth gauge (1) to the product
as described above and adjust to desired width (Fig. I, A) and depth (Fig. I, B).
• Place the product laterally against the workpiece.
• Guide the product along the edge, repeat until the desired depth has been reached.
04
Blade protection foot (Fig. J)
Lift the rear of the product and switch the product off to let it rest on the blade
protection foot (11) especially if the setting of planing depth should be kept for next
cutting process.
After use
• Switch the product off, wait for complete stop, disconnect it from the power supply,
let it cool down.
• Check, clean and store the product as described below.
22
