• Take the cutting channel into consideration when cutting along
marked cutting lines. Do not cut directly on the line but next to it.
• It is recommended to make a trial cut before working on the actual
workpiece to determine the position and width of the cutting channel,
especially after replacing the blade or changing bevel angle.
• Switch the product off, let it come to a complete stop and disconnect
it from the power supply if the saw blade gets stuck in the workpiece.
Only then free the jammed blade.
1. Cut in the direction of the wood grain whenever possible to avoid jamming the saw
blade and fraying edges.
2. Always add cooling liquid along the cutting line to reduce heat when cutting metal.
3. Ensure that there is sufcient clearance for the saw blade under the workpiece.
4. Hold the product with one hand on the handle (3), and with the other hand on the
gripping surface (16).
5. Switch the product on and wait until it runs at full speed before placing it on the
workpiece.
6. Carefully lead the product toward the workpiece. Place the base plate (8) at on
the workpiece and push the product at an even speed.
7. Only apply as much forward and vertical pressure as necessary to keep the prod-
uct at on the workpiece. Higher pressure will not increase but lower the perfor-
mance of the product and lead to uneven results.
8. Keep the product moving at all times, do not stop in one position to avoid grooves.
9. Lift the product from the workpiece before switching it off.
After use
1. Switch the product off, wait for complete stop, disconnect it from the power supply,
let it cool down and remove the blade.
2. Check, clean and store the product as described below.
04
Pendulum selector
Adjust the pendulum speed according to the workpiece material and thickness.
Illustration Position Pendulum speed Application
0 Off
Fine cuts in thin workpieces;
Cutting tight curves or circles;
cutting metal.
I Slow
Hard workpieces (e.g.
chipboard).
II Medium
Thick workpieces (e.g. wood
and plastics).
III Fast
Fast cuts in soft materials
(e.g. softwood); cutting in the
direction of the wood grain.
Operation
01
Cutting (Fig. H)
WARNING! During operation ne dust will be generated!
These dusts are highly inammable and explosive! Do not smoke during
operation, keep heat sources and open ames out of the working area!
Always wear a dust mask to protect yourself against hazards resulting
from ne dust!
