17
WARNING! This product produces an electromagnetic
eld during operation! This eld may under some
circumstances interfere with active or passive
medical implants! To reduce the risk of serious or fatal
injury, we recommend persons with medical implants
to consult their doctor and the medical implant
manufacturer before operating this product!
Product description
Part index
The index below refers to Fig. 1 on page 4.
1. Cord guard and power cord
2. On/off switch
3. Speed dial
4. Air vents
5. Carbon brush cover (x2)
6. Fine depth adjustment wheel
7. Scale for cutting depth
8. Quick release lever
(for cutting depth adjustment)
9. Locking lever
(for cutting depth adjustment)
10. Spindle lock
11. Base plate
12. Clamp nut with collet
(1/4” for UK; 6mm for EU)
13. Parallel guide xing knob
14. Parallel guide assembly
a. Angle bracket
b. Screw
c. Wing nut
15. Roller guide assembly
a. Fixing knob
b. Fine adjustment knob
c. Roller guide
16. Template guides (16 mm)
17. Wrench
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 17 6/6/18 8:40 AM
