254MM (10”) COMPOUND MITRE SAW
254MM (10”) COMPOUND MITRE SAW
254MM (10”) COMPOUND MITRE SAW
254MM (10”) COMPOUND MITRE SAW
21
23
15. SPANNER STORAGE
16. STOP LATCH
17. PIOVT BOLT LOCK-NUT
18. ON/OFF TRIGGER SWITCH
19. MOTOR
20. BEVEL SCALE
21. POSITIVE MITRE DETENTS
22. TABLE INSERT
23. TABLE
24. FENCE
25. BLADE
26. ARBOUR LOCK
Fig 2
22
20
19
18
17
16
15
24
25
26
