Pipe Outside Schedule Former Counter Bend
size Diameter CLR Wall Thickness Part# Part#
1/4” .520 1.4 / 36mm 40 / .088 T00-153RO36P0250 T00-155P0250
3.8” .680 1.4 / 36mm 40 / .091 T00-153RO36P0375 T00-155P0375
3/8” .680 2.2 / 56mm 10 / .065 T00-153RO56P0375 T00-155P0375
1/2” .840 1.8 / 46mm 40 / .109 T00-153RO46P0500 T00-155P0500
1/2” .840 2.2 / 56mm 10 / .083 T00-153RO56P0500 T00-155P0500
1/2” .840 2.6 / 67mm 5 / .065 T00-153RO67P0500 T00-155P0500
3/4” 1.050 2.2 / 56mm 40 / .113 T00-153RO56P0750 T00-155P0750
3/4” 1.050 2.6 / 67mm 10 / .083 T00-153RO67P0750 T00-155P0750
3/4” 1.050 3.2 / 82mm 5 / .065 T00-153RO82P0750 T00-155P0750
1” 1.315 2.6 / 67mm 40 / .133 T00-153RO67P1000 T00-155P1000
1” 1.315 3.2 / 82mm 10 / .109 T00-153RO82P1000 T00-155P1000
1” 1.315 4.4 / 112mm 5 / .065 T00-153R112P1000 T00-155P1000
1-1/4” 1.660 3.5 / 90mm 40 / .140 T00-153RO90P1250 T00-155P1250
1-1/4” 1.660 3.9 / 100mm 40 / .140 T00-153R100P1250 T00-155P1250
1-1/4” 1.660 5.1 / 130mm 10 / .109 T00-153R130P1250 T00-155P1250
1-1/4” 1.660 5.9 / 150mm 5 / .065 T00-153R150P1250 T00-155P1250
1-1/4” 1.660 7.5 / 190mm 5 / .065 T00-153R190P1250 T00-155P1250
1-1/2” 1.900 3.9 / 100mm 40 / .145 T00-153R100P1500 T00-155P1500
1-1/2” 1.900 5.1 / 130mm 40 / .145 T00-153R130P1500 T00-155P1500
1-1/2” 1.900 5.9 / 150mm 40 / .145 T00-153R150P1500 T00-155P1500
1-1/2” 1.900 6.7 / 170mm 10 / .109 T00-153R170P1500 T00-155P1500
1-1/2” 1.900 7.5 / 190mm 5 / .065 T00-153R190P1500 T00-155P1500
2” 2.375 5.1 / 130mm 40 / .154 T00-153R130P2000 T00-155P2000
2” 2.375 5.9 / 150mm 10 / .098 T00-153R150P2000 T00-155P2000
2” 2.375 7.5 / 190mm 5 / .079 T00-153R190P2000 T00-155P2000
2-1/2” 2.875 9.8 / 250mm 40 / .203 T00-157R250P2500 T00-155P2500
2-1/2” 2.875 10.2 / 260mm 10 / .098 T00-157R260P2500 T00-155P2500
2-1/2” 2.875 11.8 / 300mm 5 / .079 T00-157R300P2500 T00-155P2500
Pipe Tooling
Tube Outside Minimum Former Counter Bend
size Diameter CLR Wall Thickness Part# Part#
3/8” .3750 1.4 .065 T00-1582AR0360375 T00-1591A0375
3/8” .3750 1.8 .049 T00-1582AR0460375 T00-1591A0375
1/2” .5000 1.4 .065 T00-1582AR0360500 T00-1591A0500
1/2” .5000 1.8 .049 T00-1582AR0460500 T00-1591A0500
5/8” .6250 1.4 .065 T00-1582AR0360625 T00-1591A0625
5/8” .6250 1.8 .049 T00-1582AR0460625 T00-1591A0625
5/8” .6250 2.6 .039 T00-1583AR0670625 T00-1591A0625
3/4” .7500 1.8 .120 T00-1582AR0460750 T00-1591A0750
3/4” .7500 2.6 .065 T00-1583AR0670750 T00-1591A0750
7/8” .8750 2.6 .120 T00-1583AR0670875 T00-1591A0875
7/8” .8750 3.2 .065 T00-1583AR0820875 T00-1591A0875
7/8” .8750 4.4 .049 T00-1586AR1120875 T00-1591A0875
1” 1.000 3.0 .120 T00-1583AR0761000 T00-1591A1000
1” 1.000 3.2 .120 T00-1583AR0821000 T00-1591A1000
1” 1.000 3.9 .065 T00-1585AR1001000 T00-1591A1000
1” 1.000 4.4 .078 T00-1586AR1121000 T00-1591A1000
1” 1.000 5.1 .083 T00-1587AR1301000 T00-1591A1000
1” 1.000 5.9 .049 T00-1588AR1501000 T00-1591A1000
1-1/4” 1.250 5.1 .120 T00-1587AR1301250 T00-1591A1250
1-1/4” 1.250 5.9 .109 T00-1588AR1501250 T00-1591A1250
1-1/4” 1.250 6.6 .095 T00-1589AR1701250 T00-1591A1250
1-1/4” 1.250 7.4 .083 T00-15810AR1901250 T00-1591A1250
1-1/2” 1.500 5.9 .120 T00-1588AR1501500 T00-1591A1500
1-1/2” 1.500 6.6 .109 T00-1589AR1701500 T00-1591A1500
1-1/2” 1.500 7.4 .095 T00-15810AR1901500 T00-1591A1500
2” 2.000 5.9 .120 T00-1588AR1502000 T00-1591A2000
2” 2.000 6.6 .109 T00-1589AR1702000 T00-1591A2000
2” 2.000 7.4 .095 T00-15810AR1902000 T00-1591A2000
Square Tube Tooling
Pipe Outside Minimum Wall Former Counter Bend
size Diameter CLR Thickness Part# Part#
Round Tube Tooling
1/4” .250 1.4 / 36mm .039 T00-153RO36T0250 T00-154T0250
3/8” .375 1.4 / 36mm .039 T00-153RO36T0375 T00-154T0375
1/2” .500 1.4 / 36mm .039 T00-153RO36T0500 T00-154T0500
5/8” .625 1.4 / 36mm .039 T00-153RO36T0625 T00-154T0625
5/8” .625 1.8 / 46mm .079 T00-153RO46T0625 T00-154T0625
3/4” .750 1.8 / 46mm .079 T00-153RO46T0750 T00-154T0750
3/4” .750 2.2 / 56mm .059 T00-153RO56T0750 T00-154T0750
3/4” .750 2.6 / 67mm .039 T00-153RO67T0750 T00-154T0750
7/8” .8750 1.8 / 46mm .079 T00-153RO46T0875 T00-154T0875
7/8” .8750 2.2 / 56mm .059 T00-153RO56T0875 T00-154T0875
7/8” .8750 2.6 / 67mm .039 T00-153RO67T0875 T00-154T0875
1” 1.000 2.2 / 56mm .079 T00-153RO56T1000 T00-154T1000
1” 1.000 2.6 / 67mm .059 T00-153RO67T1000 T00-154T1000
1” 1.000 3.2 / 82mm .039 T00-153RO82T1000 T00-154T1000
1-1/8” 1.125 2.2 / 56mm .098 T00-153RO56T1125 T00-154T1125
1-1/8” 1.125 2.6 / 67mm .079 T00-153RO67T1125 T00-154T1125
1-1/8” 1.125 3.2 / 82mm .039 T00-153RO82T1125 T00-154T1125
1-1/4” 1.250 2.6 / 67mm .098 T00-153RO67T1250 T00-154T1250
1-1/4” 1.250 3.2 / 82mm .079 T00-153RO82T1250 T00-154T1250
1-1/4” 1.250 4.4 / 112mm .039 T00-153R112T1250 T00-154T1250
1-3/8” 1.375 3.2 / 82mm .079 T00-153R112T1375 T00-154T1375
1-3/8” 1.375 4.4 / 112mm .039 T00-153R112T1375 T00-154T1375
1-1/2” 1.500 3.5 / 90mm .118 T00-153R090T1500 T00-154T1500
1-1/2” 1.500 3.9 / 100mm .079 T00-153R100T1500 T00-154T1500
1-1/2” 1.500 4.4 / 112mm .079 T00-156R100T1500 T00-154T1500
1-1/2” 1.500 5.1 / 130mm .059 T00-153R130T1500 T00-154T1500
1-1/2” 1.500 5.9 / 150mm .047 T00-153R150T1500 T00-154T1500
1-1/2” 1.500 6.7 / 170mm .039 T00-156R170T1500 T00-154T1500
1-1/2” 1.500 7.5 / 190mm .039 T00-153R190T1500 T00-154T1500
1-5/8” 1.625 3.5 / 90mm .118 T00-153R090T1625 T00-154T1625
1-5/8” 1.625 3.9 / 100mm .079 T00-153R100T1625 T00-154T1625
1-5/8” 1.625 5.1 / 130mm .059 T00-153R130T1625 T00-154T1625
1-5/8” 1.625 5.9 / 150mm .047 T00-153R150T1625 T00-154T1625
1-5/8” 1.625 6.7 / 170mm .039 T00-156R170T1625 T00-154T1625
1-5/8” 1.625 7.5 / 190mm .039 T00-153R190T1625 T00-154T1625
Pipe Outside Minimum Wall Former Counter Bend
size Diameter CLR Thickness Part# Part#
1-3/4” 1.750 3.9 / 100mm .118 T00-153R100T1750 T00-154T1750
1-3/4” 1.750 5.1 / 130mm .098 T00-153R130T1750 T00-154T1750
1-3/4” 1.750 5.9 / 150mm .098 T00-156R150T1750 T00-154T1750
1-3/4” 1.750 6.7 / 170mm .059 T00-153R170T1750 T00-154T1750
1-3/4” 1.750 7.5 / 190mm .039 T00-153R190T1750 T00-154T1750
1-7/8” 1.875 3.9 / 100mm .118 T00-153R100T1875 T00-154T1875
1-7/8” 1.875 5.1 / 130mm .098 T00-153R130T1875 T00-154T1875
1-7/8” 1.875 5.9 / 150mm .079 T00-156R150T1875 T00-154T1875
1-7/8” 1.875 6.7 / 170mm .059 T00-153R170T1875 T00-154T1875
1-7/8” 1.875 7.5 / 190mm .039 T00-153R190T1875 T00-154T1875
2” 2.000 4.7 / 120mm .118 T00-153R120T2000 T00-154T2000
2” 2.000 5.1 / 130mm .118 T00-156R130T2000 T00-154T2000
2” 2.000 5.9 / 150mm .098 T00-153R150T2000 T00-154T2000
2” 2.000 6.7 / 170mm .079 T00-156R170T2000 T00-154T2000
2” 2.000 7.5 / 190mm .059 T00-153R190T2000 T00-154T2000
2-1/8” 2.125 4.7 / 120mm .138 T00-153R120T2125 T00-154T2125
2-1/8” 2.125 5.1 / 130mm .118 T00-153R130T2125 T00-154T2125
2-1/8” 2.125 5.9 / 150mm .079 T00-153R150T2125 T00-154T2125
2-1/8,” 2.125 6.7 / 170mm .079 T00-156R170T2125 T00-154T2125
2-1/8” 2.125 7.5 / 190mm .059 T00-153R190T2125 T00-154T2125
2-1/4” 2.250 5.1 / 130mm .118 T00-153R130T2250 T00-154T2250
2-1/4” 2.250 5.9 / 150mm .098 T00-153R150T2250 T00-154T2250
2-1/4” 2.250 6.7 / 170mm .079 T00-156R170T2250 T00-154T2250
2-1/4” 2.250 7.5 / 190mm .079 T00-153R190T2250 T00-154T2250
2-3/8” 2.375 5.1 / 130mm .118 T00-153R130T2375 T00-154T2375
2-3/8” 2.375 5.9 / 150mm .098 T00-153R150T2375 T00-154T2375
2-3/8” 2.375 6.7 / 170mm .079 T00-156R170T2375 T00-154T2375
2-3/8” 2.375 7.5 / 190mm .079 T00-153R190T2375 T00-154T2375
2-1/2” 2.500 8.9 / 225mm .079 T00-157R225T2500 T00-154T2500
2-1/2” 2.500 9.8 / 250mm .079 T00-157R250T2500 T00-154T2500
2-1/2” 2.500 10.2 / 260mm .059 T00-157R260T2500 T00-154T2500
2-1/2” 2.500 11.8 / 300mm .049 T00-157R300T2500 T00-154T2500
3” 3.000 9.8 / 250mm .156 T00-157R250T3000 T00-154T3000
3” 3.000 10.2 / 260mm .118 T00-157R260T3000 T00-154T3000
3” 3.000 11.8 / 300mm .079 T00-157R300T3000 T00-154T3000
NOTE: Larger materials may slip slightly in former during bend cycle.
