13
Step 5: Installing the tabletop and control box
Secure the tabletop (1) to the base assembly with twelve ST4.2 screws (F). The distance
between the edges of the tabletop and the supporting beam (4) should be no more than
200mm.
Secure the control panel (9) to the tabletop with two ST4.2 screws (F).
F (x14)
F
9
2
Note:
The control box (2) will already be attached to the tabletop.
1
