Ergolux ELSTD1MTMBA - Page 15

15
Step 7: Connecting cables
Connect the control panel (9) and the power cable (8) to the control box (2). Use the cable
ties (11) if necessary.
8
9
11
2
Power port for
power cable
Port for cable
connected to columns
Port for cable connected to
the control box
