888-97-395-G-01 rev. E • 05/16

7.9"- 12" (200-306mm)

9"- 15"

(230-380mm)

5.3"- 9.5"

(135-241mm)

< 0.9" (23mm)

Min-Max Outside Dimensions:

ENGLISH

Set the racheting arm to ﬁ t your size tablet and allowing for centered mounting.

There are two options for the racheting arm:

OPTION 1. As shipped, arm can be adjusted.

OPTION 2. Lock arm in place. Install the long pin into the left slot.

Optional.

Features & Speciﬁ cations

OPTION 1 OPTION 2
