Ergotron LX Wall Mount LCD Arm User Manual

2 of 12
888-45-041-W-02 rev.N • 09/11
AB CD
1
2
3
4
7 - 20 lbs
(3.2 - 9.1 kg)
M4 x 10mm
4x
M4 x 10mm
4x
4mm
1x
1x
1x
M3 x 6mm
5°
70°
180°
360°
180°
13"
(330 mm)
1x
1x
1x
1x
1x
1/8"
4x
10-24 x 1/2"
2x
13mm
2
1
1x
2.5mm
Ø 3/8" (10 mm)
Concrete
Concreto
Béton
Massivbeton
Beton
Cemento
コンクリート
水泥质
콘크리트
Ø 3/16" (5 mm)
Wood
Madera
Bois
Solide Holzbalkenträger
Massief Houten Pilaren
Due montanti in legno massiccio
木
木质
나무
Stud Finder
Localizador de largueros de madera
Stud Finder
Auswahl von Montagematerial
Positiebepaler balken
Rilevatore di montanti
スタッドファインダー
螺栓探测器
스터드 파인더
M8 x 80mm
2x
2x
1x
