Ergotron Neo-Flex Ceiling Mount User Manual

3 of 12
888-61-038-G-00 rev. B • 02/13
1/4”
14mm
Screws / Hardware for Flat Panel (PN: 697-613)
Part # Qty Description
M-A 4 Philips screws M4 x 15mm
M-B 4 Philips screws M4 x 30mm
M-C 4 Philips screws M5 x 15mm
M-D 4 Philips screws M5 x 30mm
M-E 4 Philips screws M6 x 15mm
M-F 4 Philips screws M6 x 30mm
M-G 4 Philips screws M8 x 15mm
M-H 4 Philips screws M8 x 30mm
M-I 4 Round Spacers: M6-M8 x 5mm
M-J 4 Round Spacers: M6-M8 x 10mm
M-K 4 Round Washers: M4-M5
M-L 4 Round Washers: M6-M8
Specialty Hardware Kit
Part # Qty Description
P-A 4 Lag Bolts
P-B 4 M10 Steel Washers
Specialty Hardware Kit
Part # Qty Description
P-C 2 M6x8mm Long Hex Head Screw
P-D 2 M6 Steel Washer
P-E 1 Allen Wrench 2.5mm
Contents
Part # Qty Description
1 1 Ceiling Plate
2 1 Celing Plate Cover
31NPT pipe
4 1 NPT Pipe Set Scew
5 1 Single Tilt Head
6 1 Tilt Head Adjustment Screw
71Tilt Pins
8 1 VESA Monitor Plate
94M8 Hex Screw
10 1 Universal Monitor Adapter
11 4 M8Nylock Nut
2
1
3
4
M-A M-B M-C M-D M-E M-F M-G M-H
M-I M-J M-K M-L
P-A
P-B
P-C P-D
P-E
5
6
7
8
10
11
ENGLISH
Components
Tools Needed

Ergotron Neo-Flex Ceiling Mount Specifications

General

Brand	Ergotron
Model	Neo-Flex Ceiling Mount
Category	TV Mount
Language	English
