Ergotron Neo-Flex Assembly Instructions

888-45-050-00 rev.B • 05/06
2 of 12
WARNING:
Ensure that the wall structure is capable of supporting four times the total weight of mounted equipment. Mounting to wall
surfaces that do not meet this criteria may result in an unstable, unsafe condition which could lead to personal injury and/or
property damage. Consult a construction professional if you have any doubt about what this means in regard to your particular
application.
AVISO:
Verifi que que la pared donde vaya a instalar el Soporte de pared es capaz de soportar 4 veces el peso total del equipamiento
a instalar. El montaje del monitor en una pared que no cumpla estos requisitos puede conducir a una instalación inestable e
insegura y derivar en daños personales y/o de la pared y el monitor. Consulte a un instalador profesional si tiene dudas respecto
de su caso particular.
ATTENTION:
Assurez vous que le mur sur lequel vous allez monter est capable de supporter 4 fois le poids total du matériel. Un montage sur
une surface critique peut générer une faiblesse dans l’installation et causer des dommages corporels et/ou matériels. En cas de
doute, contactez un professionnel.
1
Wood
Madera
Bois
Concrete
Concreto
Béton
3 4
Stud fi nder
Ø 3/8" (10 mm)
Concrete
Concreto
Béton
Ø 3/16" (5 mm)
Wood
Madera
Bois
ATTACH TO WALL
ATORNILLE A LA PARED
FIXATION SUR LE MUR

Ergotron Neo-Flex Specifications

General

Pan range	0 - 24 °
Tilt angle range	0 - 25 °
Angle of rotation	90 °
Mounting type	Ceiling
Maximum VESA mount	600 x 400 mm
Minimum VESA mount	200 x 100 mm
Maximum screen size	65 \
Minimum screen size	32 \
Maximum weight capacity	56.7 kg
Panel mounting interface	200 x 100, 200 x 200, 280 x 150, 300 x 100, 300 x 200, 300 x 300, 360 x 304, 400 x 200, 400 x 300, 400 x 400, 400 x 600, 420 x 240, 420 x 410, 500 x 350, 540 x 360, 600 x 200, 600 x 400 mm
Number of displays supported	1
Mounting kit	Yes
Package weight	10900 g
Safety	RoHS
Product color	Black
Harmonized System (HS) code	85299097
