Ergotron Neo-Flex Assembly Instructions

888-45-050-00 rev.B • 05/06
5 of 12
WARNING:
Anchors that are not fully set in solid concrete will not support the applied
load resulting in an unstable, unsafe condition which could lead to personal
injury and/or property damage. Consult a construction professional if you
have any doubt about what this means in regard to your particular situation.
AVISO:
Los tacos deben introducirse por completo en el ladrillo u hormigón, pues de
otro modo no soportarán el peso de su monitor, dando lugar a una insta-
lación inestable e insegura que puede ocasionar lesiones personales y / o
daños en el monitor y la pared. Consulte a un instalador profesional si tiene
dudas al respecto de su caso particular.
ATTENTION :
Des chevilles qui ne sont pas entièrement insérées dans le béton risquent de
créer une faiblesse dans le montage et d’entraîner des dommages corporels
et/ou matériels. En cas de doute, contactez un professionnel.


13 mm
d
M8 x 80mm
2x
2x
2x
e
f
6
Concrete
Concreto
Béton
8mm

Ergotron Neo-Flex Specifications

General

Pan range	0 - 24 °
Tilt angle range	0 - 25 °
Angle of rotation	90 °
Mounting type	Ceiling
Maximum VESA mount	600 x 400 mm
Minimum VESA mount	200 x 100 mm
Maximum screen size	65 \
Minimum screen size	32 \
Maximum weight capacity	56.7 kg
Panel mounting interface	200 x 100, 200 x 200, 280 x 150, 300 x 100, 300 x 200, 300 x 300, 360 x 304, 400 x 200, 400 x 300, 400 x 400, 400 x 600, 420 x 240, 420 x 410, 500 x 350, 540 x 360, 600 x 200, 600 x 400 mm
Number of displays supported	1
Mounting kit	Yes
Package weight	10900 g
Safety	RoHS
Product color	Black
Harmonized System (HS) code	85299097
